DIY500AMP.COM Design – 3S to 20S LED Battery Detection Board for Li-ion & LiFePO4 Packs
Quickly diagnose wiring issues on your BMS or custom battery builds with our 3S–20S LED Detection Board. Whether you're working on a 4S LiFePO4 setup or a full 16S high-voltage pack, this tool gives you an instant visual check of each cell’s connection.
Features:
-
Supports 3S to 20S battery configurations.
-
Bright LED Indicators show active cell connections at a glance.
-
Dual Pitch Compatibility: Works with 2.0mm and 2.54mm balance lead connectors.
-
No Cable Included: Use with your existing balance leads or grab one from our accessories section.
-
Compact & Lightweight: Easy to toss in your toolbox or take on-site.
Applications:
-
Li-ion and LiFePO4 battery builds
-
Balance lead verification
-
BMS wiring validation
-
Battery maintenance and testing
Board Size: 65mm x 40mm x 1.6mm
Material: Durable fiberglass PCB
What’s Included:
-
1x LED Detection Board (no cable included)
🛠️ A simple, reliable tool every battery builder should have on hand — saves time and prevents costly mistakes.
