Description
🔧 DIY500AMP.COM TOOL RECOMMENDATION
Perfect for RC enthusiasts, EV hobbyists, and DIY battery builders, this compact 200A Digital Power Analyzer is essential for real-time monitoring of current, voltage, wattage, capacity, and discharge time. Whether you're testing a new eBike battery, tuning a solar setup, or verifying your custom pack’s performance, this tool delivers precision every time.
✅ Product Highlights:
-
Accurate Readings
- Voltage: 0–60V (Resolution: 0.01V)
- Current: 0–200A (Resolution: 0.01A)
- Power: 0–6554W (Resolution: 0.1W)
- Capacity: 0–65Ah (Resolution: 0.001Ah)
- Works from 6V–60V input
-
Backlit LCD Display
Large 16×2 backlit screen for clear readings in any lighting condition. -
Smart Functions
- Peak voltage detection
- Energy accumulation (Wh)
- Capacity tracking (Ah)
- Real-time load monitoring
-
Durable Build
Built with tinned copper internal wiring, ABS housing, and ventilation ports to reduce heat and prolong life.
📦 What’s Included:
- 1× 200A Watt & Amp Meter
- Preinstalled XT60 connectors (for plug-and-play use)
📐 Specifications:
- Working Voltage: 6–60V
- Current Range: 0–200A
- Voltage Range: 0–60V
- Power Range: 0–6554W
- Capacity Range: 0–65Ah
- Energy Range: 0–6554Wh
- Display: 16×2 Backlit LCD
- Dimensions: 85 × 43 × 20 mm (3.35 × 1.69 × 0.79 in)
- Weight: 80g
- Material: ABS
- Model: High Precision Watt Meter
- Brand: Shunmaii
- Origin: Mainland China
🔋 Use Cases:
- RC battery testing
- Spot welding performance analysis
- Power efficiency testing for solar & EV setups
- Battery discharge monitoring
- Inline amp draw readings for high-current builds
💡 DIY500AMP.COM Design Note:
If you build or test lithium battery packs, especially for eBikes or spot welders, this tool gives you real insight into system performance. One of the most affordable ways to protect your time and cells.
